MIG welding machine LCD 250A
Product Code: EMIG250LCDIII
EAN: 8720028142798
PRODUCT DESCRIPTION
The Hugong EMIG250LCD is a powerful machine for MIG/MAG and MMA (electrode) welding. This industrial inverter welder is mounted on a sturdy chassis and equipped with an integrated 4-roll wire feed unit, which ensures stable and even wire feed - even for longer welds or thicker wire diameters.
It supports 2T/4T modes and features an LCD display for setting current, voltage and inductance. The EMIG250LCD is suitable for welding steel, stainless steel, aluminum and filled wire. Its rugged construction and compact design make it easy to move within the workshop without sacrificing power.
- MIG/MMA welding installation with integrated trolley
Sturdy, mobile solution with machine and gas cylinder combined on one wheeled unit.
- 4-roll wire feed unit
Ensures constant wire feed even with long welds or aluminum.
- Stepless adjustment
Precisely set wire feed, voltage, and inductance for full arc control.
- LCD display and 2T/4T function
Clear operation and suitable for continuous or repetitive tasks.
- ABS shockproof housing & 5-year warranty after registration
Rugged casing for protection against impact, dust, and light moisture. Warranty extends to 5 years with online registration.
Supplied with:
- MIG-torch MLT24M4 - 4 meters
- Ground clamp with 3-meter cable (25 mm²)
- 3m Ø8 mm gas hose with NW5 coupling
- Wire feed rollers 0.8/1.0V, 1.0/1.2V
- Contact tips 0.8 mm, 1.0 mm, 1.2 mm
Technical specifications
- Frequency = 50/60 Hz
- Voltage = 400V - 3 Phase
- No load voltage = 66V
- Input power = 5.2kVA
- Rated input current = 13A
- Duty cycle @20C = 80% - 250A
- Duty cycle @40C = 60% - 250A
- Welding current range = MIG 30 - 250A / MMA 30 - 200A
- Isolation class = IP21S
Dimensions and weights
- Weight =69.2Kg
- Product weight =52.0Kg
- Length =958.0mm
- Width =570.0mm
- Height =820.0mm
- Product Length =900.0mm
- Product Width =495.0mm
- Product Height =720.0mm
