Electrode welding machine 120A

Welding and cutting equipment / Electrode welding machines

Product Code: EXTREME120III

EAN: 8720028142712

https://www.hugongwelds.eu/web/image/product.template/83553/image_1920?unique=922f03b

€ 0.00 0.0 EUR € 0.00

  • Voltage
  • Rated input current
  • Frequency
  • Input power
  • Circuit breaker
  • No load voltage
  • Welding current range
  • Duty cycle @20C
  • Duty cycle @40C
  • Welding electrodes
  • Isolation class

This combination does not exist.

Contact Us
  • Stepless adjustment
  • Mobile
  • Digital display
  • ABS shock-resistant housing
  • 5-year warranty upon registration

PRODUCT DESCRIPTION

The Hugong Extreme120 is a powerful, compact, and lightweight electrode welding machine, developed for mobile use. Its handy design and easily adjustable welding current make it especially suitable for on-site work and welding tasks involving various material thicknesses.

Modern IGBT inverter technology ensures a stable arc, high efficiency, and reliable performance. An integrated cooling fan and thermal protection system guard the machine against overheating, even during intensive use. The hot-start and anti-stick functions simplify arc ignition and help prevent the electrode from sticking to the workpiece.

The Extreme120 is suitable for welding carbon steel, low-alloy steel, and stainless steel, and works perfectly with both rutile (E6013) and basic (E7018) electrodes in the 1.6 to 3.2 mm range.

  • Stepless adjustment

The welding current can be adjusted smoothly and precisely via a rotary knob. This ensures accurate matching to material, electrode, and desired weld depth.

  • Mobile

Thanks to inverter technology, the device is lightweight and compact. Combined with the shoulder strap, it is easy to carry.

  • Digital display

The digital screen clearly shows the set welding current.

  • ABS shock-resistant housing

The ABS housing provides protection against impacts, dust, and light moisture.

  • 5-year warranty upon registration

Long-term security thanks to extended factory warranty after online registration.

Supplied with:

  • Electrode holder with 3-meter welding cable 10mm²
  • Ground clamp with 2-meter cable 10mm²
  • Neoprene power cable
  • Shoulder strap

Technical specifications

  • Voltage = 230V - 1 Phase
  • Rated input current = 23A
  • Frequency = 50/60 Hz
  • Input power = 5.06kVA
  • Circuit breaker = 16A B-char
  • No load voltage = 65V
  • Welding current range = 20 - 120A
  • Duty cycle @20C = 30% - 120A
  • Duty cycle @40C = 15% - 200A
  • Welding electrodes = 1.6 - 2.5m
  • Isolation class = IP21S

Dimensions and weights

  • Weight =3.0Kg
  • Product weight =2.65Kg
  • Length =325.0mm
  • Width =225.0mm
  • Height =230.0mm
  • Product Length =315.0mm
  • Product Width =102.0mm
  • Product Height =176.0mm
