Product Code: MFL30D
EAN: 8720028053445
PRODUCT DESCRIPTION
Flat cylinder double
The stroke from the double cylinders is higher then the stroke from the single cylinders.
This cylinder is suit for working in narrowness.
The surface of the plunger is finished with a chrome plate.
output = 30 Ton
stroke = 53mm
effective area = 33,1cm^2
oil capacity = 0,058 L
height of product = 63mm
extended height = 118mm
outside diameter = 115x95mm
bore diameter = 75mm
plunger diameter = 63mm
max. pressure = 700bar
Technical specifications
Dimensions and weights
- Weight =5.0Kg
- Product weight =4.5Kg
- Length =260.0mm
- Width =155.0mm
- Height =110.0mm
- Product Length =185.0mm
- Product Width =95.0mm
- Product Height =120.0mm
